Industrial - swtiches

ALLNET Switch industrial full managed Layer2+  6 Port GbE • PoE Budget 360W • 4x PoE bt • 2x SFP • Fanless • DIN • ALL-SGI8106PMJ-BT Highlights: 4 Gigabit ports with PoE AF/AT/BT support up to 90 watts per port 2x SFP ports for fibre optic GBIC e.g. ALL4750/4751-INDU etc. PoE ports 1-4 max. PoE IEEE802.3bt 90W Layer2+ features such as 802.1Q VLAN, port isolation IGMP, LLDP, PoE+ management, IP source guard, ACLs etc. Supports spanning tree STP (802.1D) and RSTP (802.1W) and MSTP (802.1s) Supports PoE management such as PoE scheduling, PoE PD-alive, port PoE priority, soft reboot PoE non-stop Supports G.8032 quick ring protocol. Self-healing <20ms Max. PoE budget = 360 watts Freeless metal housing with optimised heat dissipation Easy to use as a table-top device, wall-mounted or top-hat rail Extended temperature range from -40°C ~ +75°C NEW: PoE & LAN JSON Java script notation API for ON/OFF üvia remote ALLNET ALL-SGI8106PMJ-BT Industrial Switch is a managed Layer 2+ Gigabit BT PoE switch with 4-port Gigabit IEEE802.3af/at/bt PoE + 2-port Gigabit SFP optical port. It is specially designed to build a full Gigabit backbone to transmit reliable and fast data in demanding industrial environments and to forward data to a remote network via fibre optic cable. It has a robust IP40 enclosure and a redundant power supply system. The industrial managed switch offers user-friendly but advanced IPv6/IPv4 management interfaces and a soft reboot PoE non-stop function. It is the best investment for industrial companies to expand or upgrade their network infrastructure and can also be used for the lighting industry, security surveillance, enterprise parks and other applications. Intelligent PD alive testing for frozen PDs The ALL-SGI8106PMJ-BT industrial PoE switch with 4 ports can be configured to monitor the status of the connected PDs in real time. As soon as the PD stops working and responding, the ALL-SGI8106PMJ-BT restarts the power supply to the PoE port and gets the PD up and running again. In addition, reliability is significantly improved by the fact that the PoE port resets the PD power supply, reducing the administrative burden on the administrator. PoE schedule function for energy saving To protect the environment, the ALL-SGI8106PMJ-BT Ethernet PoE switch can effectively control the power supply in addition to its ability to deliver high wattage. The PoE schedule function helps to enable or disable the PoE power supply for each PoE port during specific time intervals and is a powerful feature that helps SMEs or enterprises to save power and money. Planned PD restart The intelligent PoE switch ALL-SGI8106PMJ-BT allows each of the connected PoE IP cameras or PoE wireless access points to be restarted at a specific time every week. This reduces the risk of the IP camera or AP crashing due to a buffer overflow. Redundant ring with fast recovery for critical network applications The ALL-SGI8106PMJ-BT supports redundant ring technology and has a strong, fast self-recovery capability to prevent interruptions and external intrusions. It integrates advanced ITU-T G.8032 ERPS technology, Spanning Tree Protocol (802.1s MSTP) and a redundant power supply system into the customer's industrial automation network to improve system reliability and uptime in harsh factory environments. In a given simple ring network, the data link recovery time can be as low as 20 ms. 1588 time protocol for industrial computer networks The ALL-SGI8106PMJ-BT is ideal for telecommunications and carrier Ethernet applications and supports MEF service provisioning and timing-over-packet solutions for IEEE 1588 and synchronous Ethernet. Strong Layer 2 functions The ALL-SGI8106PMJ-BT Layer 2 Ethernet switch can be programmed for advanced Layer 2 switch management functions such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. By aggregating the supporting ports, the ALL-SGI8106PMJ-BT enables the operation of a high-speed trunk group that has multiple ports and also supports fail-over. Efficient and versatile management methods For efficient management, the ALL-SGI8106PMJ-BT is equipped with console, web and SNMP management interfaces. With the integrated web-based management interface, it offers a user-friendly, platform-independent management and configuration option. For text-based management, access is possible via Telnet and the console port. For standards-based monitoring and management software, it provides an SNMPv3 connection that encrypts the packet contents for secure remote management during each session. Intelligent PoE switch with SFP DDM function The ALL-SGI8106PMJ-BT supports the SFP DDM (Digital Diagnostic Monitor) function, which allows the network administrator to easily monitor real-time parameters of SFP transceivers, such as optical output power, optical input power, temperature, laser bias voltage and transceiver supply voltage. The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply unit - please order separately!  JSON-Java Script Object Notation API With the JSON API, the ADMIN can create a special user and grant this user authorisation for JSON. We have focussed on 2 functions that we consider to be important. PoE ON/OFF & LAN Port Enabled/Disabled (for switches with PoE function) LAN Port Enabled/Disabled (for switches without PoE) Technical details: Model ALL-SGI8106PMJ-BT Copper ports 4x 10/100/1000BASE-T RJ45 auto-sensing ports Fibre ports 2x 100/1000BASE-T SFP interfaces, supports 100/1000Mbps dual mode PoE ports 4x-802.3af/802.3at/bt PoE injector ports Console ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch architecture Store-and-Forward Switch Fabric 12Gbps/non-blocking Throughput 8.928Mpps @64 bytes Address Table 8K entries Share Data Buffer 4.1 Mb Jumbo Frame 9216 bytes SDRAM 1Gb Flash memory 128Mb Flow Control IEEE 802.3x pause frame for full-duplex ; Back pressure for half-duplex Reset button >2 sec: Factory default and reset Power Supply 48 ~ 57 VDC, 50/60Hz,Dual DC for PoE support 12VDC ~ 48VDC for non PoE support PoE standards IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE IEEE802.3bt PoE over Ethernet PlusPlus/PSE PoE Power Supply Type Per port 52V DC, Max. 90watts LED Indicators Power: Green Solid on--power work normal,off--power disconnected  System:Green Blink--work normally, solid on--soft work abnormal, fast blink--soft upgrade  PoE: Yellow Solid on--PoE work normally, Off--PoE doesn’t work, Blink--PoE overload 10/100/1000T RJ45 Interfaces (Port 1 to Port 4): 1 000 LNK/ACT (Green), Blink--port connected with data transmission; Solid on--port connected without data transmission  100/1000Mbps SFP Interfaces (Port 5 to Port 6): Green Blink- port connected with data transmission; Solid on- port connected without data transmission EMC 6KV surge protection (6KV common mode, 2KV differential mode), 6KV contact/8KV air ESD Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Dimension 145x112x47.2mm Weight 0.6kg Working Temperature -40°C to 75°C Storage Temperature -40°C to 80°C Operation Humidity 5% to 95%, non-condensing MTBF 50,000hrs Layer 2 functions Port configuration Auto-negotiation Flow control Port Mirror: TX/RX/BOTH; Many-to-1 monitor CPU Mirror Traffic statistics Link aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk) Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address Dynamic MAC address management VLAN 4094 Active VLANs 4094 VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Voice VLAN 802.1ad Q-in-Q tunnelling Private VLAN (Protected port) GARP/GVRP ACL 256ACLs L2, L3 e L4 Time-based ACL IP ACL MAC ACL MAC-IP ACL User-Defined ACL ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter Ring Protection <20ms G.8032 ERPS Ring Fast Ring ALLNET ring, < 20ms Multicast 256 groups IGMP v1/v2/v3 Snooping, Fast Leave MLD Snooping Multicast VLAN IGMP filter MVR Multicast routing QOS 8 mapping IDs to 8 level priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port SWRR, DWRR for Scheduling Flow Redirect Precedence TOS Rate Limiting(Ingress/Egress) Stri Priority Security Features Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) ARP Protection AAA DAI DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type; 802.1x Authentication (port-based e MAC-based) TACACS/TACACS+ Authentication RADIUS Authentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port; Port Isolation Loopback detection Management SNMP v1/v2c/v3 with Full Private MIBs RMON 4 groups WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration backup/reload Dual firmware LLDP Configuration export/import CDP Aware OAM (IEEE802.3ah) CFM (IEEE802.1ag) sFlow Telnet client Synchronisation, IEEE1588 Support IEEE1588v2 transparent clock Other Features DNS Client DHCP Relay DHCP Client DHCP Snooping DHCP Option 66 DHCP option 67 DHCP option 82 NTP/SNTP client UPNP UDLD PoE management Total PoE power budget control Per port PoE function enable/disable PoE admin-mode control PoE port power feeding priority Per PoE port power limitation PD classification detection PD alive check PoE schedule Soft-reboot PoE non-stop Maintenance Cable Diagnostics Ping SFP DDM (Digital Diagnostics Monitoring) Thermal protection System log (Local and Remote) Memory and CPU Monitoring Tracert/ Tracert 6  Layer 3 functions Static Routing IPv4 Unicast: Static Routing (Software Base) IPv6 Unicast: Static Routing (Software Base) IPV6 IPv6 neighbour discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 Ping6 Telnet(v6) Http/Https Interface IPV6 ACL IPV6

ALLNET Switch industrial full managed Layer2+ 12 Port GbE • PoE Budget 240W • 8x PoE at • 4x SFP • Lüfterless • DIN • JSON API • ALL-SGI8112PMJ Highlights: 8 Gigabit ports with PoE AF-AT support up to 30Watt per port 4x SFP ports for fibre optic Gbics e.g. ALL4750-INDU / ALL4751-INDU etc. PoE ports 1-8 max. PoE IEEE802.3at 30W Layer2+ features such as 802.1Q VLAN, port isolation IGMP, LLDP, PoE+ management, IP source guard, ACLs etc. Supports spanning tree STP (802.1D) and RSTP (802.1W) and MSTP (802.1s) Supports PoE management such as PoE scheduling, PoE PD-alive, port PoE priority, soft reboot PoE non-stop Supports G.8032 quick ring protocol. Self-healing <20ms Max. PoE budget = 240 watts Freeless metal housing with optimised heat dissipation Easy to use as a table-top device, wall-mounted or top-hat rail Extended temperature range from -40°C ~ +75°C Hat rail bracket included in the scope of delivery  NEW: PoE & LAN JSON-Java-Script-Notation API for ON/OFF üvia Remote                                                                                                                                                                                                                                                               ALL-SGI8112PMJ Industrial Switch is a managed Layer 2+ Gigabit PoE switch with 8-port Gigabit 802.3af/at PoE and 4-port Gigabit SFP slot port. It is specifically designed to build a full Gigabit backbone to deliver reliable and fast data in demanding industrial environments and to forward data to remote networks over fibre optic cables. It features a robust IP40 enclosure and a redundant power supply system. The industrial managed switch offers user-friendly but advanced IPv6/IPv4 management interfaces and a soft reboot PoE non-stop function. It is the best investment for industrial companies looking to expand or upgrade their network infrastructure. Features: Support of L2+ switching functions including 802.1Q VLAN, mirroring, port isolation, IGMP snooping, DHCP snooping, LLDP, PoE+ management, IP source guard, ARP inspection, ACLs etc. Support of Spanning Tree STP(802.1D) and RSTP(802.1W) and MSTP(802.1s) Support of extended management via WEB, CLI, TELNET, SSH, SNMP. Support for cable diagnostics Two firmware backups Supports PoE management, such as PoE schedule, PoE PD alive, port PoE priority, soft reboot PoE N on-stop Supports G.8032 quick ring protocol. Self-recovery time <20ms Supports IEEE1588 v2, transparent clock (TC) Supports DDM, SFP digital diagnostics & monitoring Supports IPV4 and IPV6 functions for static routing Supports memory and CPU monitoring 6KV &overvoltage protection (6KV common mode, 2KV differential mode), 6KV contact/8KV air ESD protection The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply - please order separately! PoE schedule function for energy saving To protect the environment, the ALL-SGI8112PMJ Ethernet PoE switch can effectively control the power supply in addition to its ability to deliver high wattage. The PoE schedule function helps to enable or disable the PoE power supply for each PoE port during specific time intervals and is a powerful feature that helps SMEs or enterprises to save power and money. Planned PD restart The ALL-SGI8112PMJ intelligent PoE switch allows each of the connected PoE IP cameras or PoE wireless access points to be restarted at a specific time every week. This reduces the risk of the IP camera or AP crashing due to a buffer overflow. Redundant ring with fast recovery for critical network applications The ALL-SGI8112PMJ supports redundant ring technology and has a strong, fast self-recovery capability to prevent interruptions and external intrusions. It integrates advanced ITU-T G.8032 ERPS technology, Spanning Tree Protocol (802.1s MSTP) and a redundant power supply system into the customer's industrial automation network to improve system reliability and uptime in harsh factory environments. In a given simple ring network, the data link recovery time can be as fast as 20 ms.   1588 time protocol for industrial computer networks The AALL-SGI8112PMJ is ideal for telecom and carrier Ethernet applications and supports MEF service provisioning and timing-over-packet solutions for IEEE 1588 and synchronous Ethernet. Strong layer 2 functions The ALL-SGI8112PMJ Layer 2 Ethernet switch can be programmed for advanced Layer 2 switch management functions such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. By aggregating the supporting ports, the ALL-SGI8112PMJ enables the operation of a high-speed trunk group that has multiple ports and also supports fail-over. Efficient and versatile management methods For efficient management, the ALL-SGI8112PMJ is equipped with console, web and SNMP management interfaces. With the integrated web-based management interface, it offers user-friendly, platform-independent management and configuration options. For text-based management, access is possible via Telnet and the console port. Intelligent PoE switch with SFP DDM function TheALL-SGI8112PMJ supports the SFP DDM (Digital Diagnostic Monitor) function, which enables the network administrator to easily monitor real-time parameters of the SFP transceivers, e.g. optical output power, optical input power, temperature, laser bias voltage and transceiver supply voltage.  The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply unit - please order separately!  JSON-Java Script Object Notation API With the JSON API, the ADMIN can create a special user and grant this user authorisation for JSON. We have focussed on 2 functions that we consider to be important.   PoE ON/OFF & LAN Port Enabled/Disabled (for switches with PoE function) LAN Port Enabled/Disabled (for switches without PoE) Technical details: Model ALL-SGI8112PMJ Copper Ports 8-10/100/1000BASE-T RJ45 auto-sensing ports Fibre ports 4-100/1000BASE-T SFP interfaces, supports 100/1000Mbps dual mode PoE ports 8-802.3af/802.3at PoE Injector Ports Console ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch architecture Store-and-Forward Switch Fabric 24Gbps/non-blocking Throughput 17.856Mpps @64 bytes Address table 8K entries Share Data Buffer 4.1 Mb Jumbo Frame 9216 bytes SDRAM 1Gb Flash memory 128Mb Flow control IEEE 802.3x pause frame for full-duplex ; Back pressure for half-duplex Reset button >2 sec: Factory default and reset Power Supply 48 ~ 57 VDC, 50/60Hz,Dual DC Power Consumption without PoE ≤12W PoE standards IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE PoE power supply type Per port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af) Per port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at) LED indicators Power: Green Solid on--power work normal,off--power disconnected System:Green Blink--work normally, solid on--soft work abnormal, fast blink--soft upgrade PoE: Yellow Solid on-PoE work normally, Off--PoE doesn’t work, Blink--PoE overload 10/100/1000T RJ45 interfaces (Port 1 to Port 8): 1000 LNK/ACT (Green), Blink--port connected with data transmission; Solid on--port connected without data transmission 100/1000Mbps SFP Interfaces (Port 9 to Port 12): Green Blink- port connected with data transmission; Solid on- port connected without data transmission EMC 6KV surge protection (6KV common mode, 2KV differential mode), 6KV contact/8KV air ESD Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Dimension 165x123x53.5mm Weight 1.0kg Working temperature -40°C to 75°C Storage Temperature -40°C to +80°C     MTBF 50,000hrs Port configuration Auto-negotiation flow control Port Mirror: TX/RX/BOTH; Many-to-1 monitor CPU Mirror Traffic statistics Link aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk) Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address Dynamic MAC address management VLAN 4094 Active VLANs 4094 VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Voice VLAN 802.1ad Q-in-Q tunnelling Private VLAN (Protected port) GARP/GVRP ACL 256ACLs L2, L3 e L4 Time-based ACL IP ACL MAC ACL MAC-IP ACL User-Defined ACL ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter Ring Protection <20ms G.8032 ERPS Ring Fast Ring Multicast 256 groups IGMP v1/v2/v3 Snooping, Fast Leave MLD Snooping Multicast VLAN IGMP filter MVR Multicast routing QOS 8 mapping IDs to 8 level priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port SWRR, DWRR for Scheduling Flow Redirect Precedence TOS Rate Limiting(Ingress/Egress) Stri Priority Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) ARP Protection AAA DAI DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type; 802.1x Authentication (port-based e MAC-based) TACACS/TACACS+ Authentication RADIUS Authentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port; Port Isolation Loopback detection SNMP v1/v2c with Full Private MIBs RMON 4 groups WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration Backup/Reload Dual firmware LLDP Configuration export/import CDP Aware OAM (IEEE802.3ah) CFM (IEEE802.1ag) sFlow Support IEEE1588v2 transparent clock Other features DNS Client DHCP Relay DHCP Client DHCP Snooping DHCP Option 66 DHCP Option 67 DHCP Option 82 NTP/SNTP Client UPNP UDLD

ALLNET Switch industrial full managed Layer2+ 18 Port GbE • PoE Budget 480W • 16x PoE at • 2x SFP • Lüfterlos , IP40 • ALL-SGI8018PM Highlights: 16x10/100/1000M PoE downlink ports, 2x1000M SFP ports Supports PoE power up to 30W/port Supports L3 management, such as OSPF, RIP, QoS, VLAN, MSTP, multi-broadcast, ports management and PoE management 6KV surge protection, 8KV contact /15KV air ESD protection Extended temperature range -40°C ~+75°C The ALLNET ALL-SGI8018PM stands out as an outstanding choice when it comes to powerful yet cost-effective industrial networking solutions. This high-quality Layer 3 PoE switch offers 18 Gigabit ports and is a remarkable combination of professionalism and affordability. The remarkable configuration includes 16 downlink ports operating at speeds of 10/100/1000 Mbps and supporting Power over Ethernet (PoE). In addition to this, the switch has 2 SFP ports at 1000 Mbps to provide even more flexibility in network connectivity. The 16 PoE downlink ports follow IEEE 802.3af/at standards and offer impressive PoE+ performance. Each of these ports can deliver up to 30 watts of power, ensuring a solid power supply for connected devices. However, the performance of the ALL-SGI8018PM goes beyond simple connectivity. It is equipped with extensive features for efficient network management. These include L3 management protocols such as OSPF and RIP, which improve routing efficiency. The switch also supports QoS, VLANs, MSTP and multi-broadcast for optimal data prioritisation and segmentation. The switch is equipped with various protection mechanisms, including 6 kV surge protection as well as 8 kV contact and 15 kV air ESD protection. This ensures network security and reliability, especially in demanding industrial environments. The installation of the ALL-SGI8018PM is extremely flexible. It can be mounted on the wall, on the table or on a top-hat rail. This versatility makes it ideal for various application scenarios, including security networks, video surveillance and general networking. Overall, the ALLNET ALL-SGI8018PM is a reliable and robust switch that combines powerful connectivity with advanced management features. Its wide range of deployment options and impressive performance make it a compelling choice for demanding network requirements. Installation examples/used cases: Industrial switches with redundant power inputs and an extended temperature range of -40°C to a maximum of 85°C offer a reliable solution for a wide range of application scenarios. Here are some specific use cases tailored to resellers in the mentioned sectors: Outdoor Telecommunication Networks: These switches are ideal for setting up mobile base stations and other telecommunication equipment installed outdoors. They ensure stable and reliable network connectivity even in extreme weather conditions. Industrial Automation: In manufacturing plants and industrial environments where seamless communication between machines and control systems is crucial, these switches provide reliable data transmission and minimize downtime. Power Distribution and Smart Grids: For monitoring and controlling power generation, distribution, and renewable energy systems, stable network connections are essential. These switches ensure reliable communication in harsh environments. Security Infrastructure: In video surveillance systems, access control, and alarm systems, these switches provide a robust network solution required in demanding security environments. IoT Implementations: When connecting IoT devices in various scenarios like agriculture, logistics, and smart cities, these switches are indispensable to ensure stable communication and data transmission. Lighting Control and Smart Lighting: In intelligent lighting systems, both indoor and outdoor, these switches offer a reliable network connection for lighting control and monitoring. Cybersecurity and Network Segmentation: These switches are particularly crucial in security-critical environments to enable network segmentation and isolation, contributing to minimizing potential attack vectors. Smarthome Integration: In sophisticated smarthome installations requiring reliable indoor and outdoor networking, these switches provide a stable network solution for seamless integration of smart devices. Outdoor WLAN Networks: These switches can be used to provide outdoor WLAN hotspots and networks in amusement parks, campgrounds, and public areas. Remote Infrastructure Monitoring: In remote locations like isolated weather stations, pipeline monitoring systems, or environmentally critical facilities, these switches enable reliable remote monitoring and control. These industrial switches offer a dependable and robust solution for a variety of use cases in the mentioned sectors. They empower resellers in the IT, lighting, telecommunications, electrical, video surveillance, security, cybersecurity, and IoT fields, as well as smarthome installers, to deliver high-quality network solutions that meet the challenges of demanding environments. Technical Details: Parameter Specifications Power supply Powered by power adaptor Range of voltage 2*DC 48~57V, redundancy power supply Consumption Self consumption<20W Downlink ports 10/100/1000Base-T 30W PoE RJ45(IEEE 802.3af/at) Uplink ports Ports 17~18 1000M SFP slots Cable and distance Use cat5e/6,100m max Standard IEEE802.3, IEEE802.3u, IEEE802.3z Switch fabric 36Gbps Though put 26.788Mpps Buffer 4M MAC address table 16K Indicator Power: 2 *red ; Uplink 9~10: green LEDs indicate Link/Act Downlink 1~8: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE Protection Surge: 6KV, standard: IEC61000-4-5 ESD: 8KV: contact/15KV: air, standard:IEC61000-4-2 Working temperature -40°C~+75°C Storage temperature -40°C~+85°C Humidity 0~95%(No condensation) Dimension(L×W×H) 165mm × 115 mm × 50mm Material Metal Colour Black Net-weight 530g L2 Features Port configuration Auto-negotiation Flow Control Port Mirror L2 Features Link Aggregation Traffic statistics Static link aggregation LACP Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP 8 groups 8 ports per group L2 Features MAC Table Aging Time Static MAC address Dynamic MAC address management L2 Features VLAN 4K Active VLANs 4K VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Management VLAN Voice VLAN Q-in-Q Private VLAN GARP/GVRP L2 Features ACL 64 ACLs L2, L3 e L4 Time-based ACL L2 Features Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter L2 Features Multicast 256 groups IGMP v1/v2/v3 Fast Leave Multicast VLAN Static Multicast Multicast Filter IGMP Statistics MLD Snooping L2 Features PoE management Support total power consumption control Support single port PoE ON/OFF Support port output priority L2 Features QOS 4 priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port Security Features Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) up to 200 entries ARP Protection DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type 802.1x Autentication (port-based e MAC-based) TACACS/TACACS+ Autentication RADIUS Autentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port Port Isolation Local User Name Password Authentication (2 levels) Loopback detection Management SNMP v1/v2c/v3 RMON 4 grupos WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration Backup/Reload All possible configurations in the CLI must exist in the WEB interface LLDP Other Features DHCP Relay DHCP Client DHCP Snooping DHCP Option 82 SNTP Client BOOTP Client Maintenance Ping and Tracert System log (Local and Remote) Memory and CPU Monitoring L3 Features Static Routing OSPFv2 RIPv1/v2 DHCP Server IPV6 IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 Ping6 Tracert6 Telnet(v6) Http/Https IPv6 TFTP Static Routing Interface IPV6

ALLNET Switch industrial full managed Layer2+ 20 Port • 20x GbE • PoE Budget 240W • 8x PoE at • 8x GbE • 4x SFP • DIN • Fanless • ALL-SGI8120PM Highlights: 8x Gigabit ports with PoE AF-AT support up to 30Watt per port 8x Gigabit ports 4x SFP ports for fibre optic GBIC e.g. ALL4750/4751-INDU etc. PoE ports 1-8 max. PoE IEEE802.3at 30W Layer2+ features like 802.1Q VLAN, Port Isolation IGMP, LLDP, PoE+ Management, IP source Guard, ACLs etc. Supports Spanning Tree STP (802.1D) and RSTP (802.1W) and MSTP (802.1s) Supports PoE management such as PoE scheduling, PoE PD-alive, Port PoE Priority, Soft-Reboot PoE Non-Stop Supports G.8032 quick ring protocol. Self-healing <20ms Max. PoE budget = 240 watts Fanless metal housing with optimised heat dissipation Easy to use as desktop, wall-mounted or top-hat rail unit Extended temperature range from -40°C ~ +75°C ALLNET ALL-SGI8120PM Industrial Switch is a Layer 2+ managed Gigabit PoE Switch that features 8-Port Gigabit 802.3af/at PoE + 8-Port Gigabit RJ45 + 4-Port Gigabit SFP optical port,is specially designed to build a full Gigabit backbone to transmit reliable and high-speed data in heavy industrial demanding environments and forward data to remote network through fiber optic cabling. It comes with an IP40 rugged case and redundant power system. The industrial managed switch provides user friendly but advanced IPv6/IPv4 management interfaces and Soft-reboot PoE Non-stop function.It is the best investment for expanding industrial business or upgrading its network infrastructure. Intelligent PD–Alive Check for Frozen PDs The ALL-SGI8112P Mindustrial PoE switch 8 ports can be configured to monitor connected PD’s status in real time. Once the PD stops working and responding, the ALL-SGI8104v2PM will reboot the PoE port power and bring the PD back to work. It also greatly enhances the reliability in that the PoE port will reset the PD power, thus reducing administrator’s management burden. PoE Schedule Function for Energy Saving For environmental protection purpose, the ALL-SGI8120PM switch Ethernet PoE can effectively control the power supply besides its capability of giving high watts power. The PoE schedule function helps to enable or disable PoE power feeding for each PoE port during specified time intervals and it is a powerful function to help SMBs or enterprises save power and money. Scheduled PD Re-starting The ALL-SGI8120PM smart switch PoE allows each of the connected PoE IP cameras or PoE wireless access points to reboot at a specific time each week. Therefore, it will reduce the chance of IP camera or AP crash resulting from buffer overflow. Fast Recovery Redundant Ring for Critical Network Applications The ALL-SGI8120PM supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments. In a certain simple Ring network, the recovery time of data link can be as fast as 20ms. 1588 Time Protocol for Industrial Computing Networks The ALL-SGI8120PM is ideal for telecom and Carrier Ethernet applications, supporting MEF service delivery and timing over packet solutions for IEEE 1588 and synchronous Ethernet. Strong Layer 2 Features The ALL-SGI8120PM layer 2 Ethernet switch can be programmed for advanced Layer 2 switch management functions such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. Via the aggregation of supporting ports, the ALL-SGI8120PM allows the operation of a high-speed trunk group that comes with multiple ports and supports fail-over as well.   Efficient and Various Management Methods For efficient management, the ALL-SGI8120PM is equipped with console, Web and SNMP management interfaces. With the built-in Web-based management interface, it offers an easy-to-use, platform-independent management and configuration facility. For text-based management, it can be accessed via Telnet and the console port. For standard-based monitor and management software, it offers SNMPv3 connection which encrypts the packet content at each session for secure remote management.   Intelligent PoE Switch SFP DDM Function The ALL-SGI8120PM supports SFP-DDM (digital diagnostic monitor) function that greatly helps network administrator to easily monitor real-time parameters of the SFP transceivers, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage. Technical Details: Model ALL-SGI8120PM Copper Ports 16-10/100/1000BASE-T RJ45 auto-sensing ports Fiber Ports 4-100/1000BASE-T SFP interfaces, supports 100/1000Mbps dual mode PoE Ports 8-802.3af/802.3at PoE Injector Ports Console Ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch Architecture Store-and-Forward Switch Fabric 40Gbps/non-blocking Throughput 29.76Mpps @64 bytes Address Table 8K entries Share Data Buffer 4.1 Mb Jumbo Frame 9216 Bytes SDRAM 1Gb Flash Memory 128Mb Flow Control IEEE 802.3x pause frame for full-duplex Back pressure for half-duplex Reset Button >2 sec.: Factory default and reset Power Supply 48 ~ 57 VDC, 50/60Hz,Dual DC with PoE 12~55VDC without PoE function PoE Standards IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE PoE Power Supply Type Per Port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af) Per Port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at) LED Indicators Power: Green Solid on--power work normal,off--power disconnected  System:Green Blink--work normally, solid on--soft work abnormal, fast blink--soft upgrade  PoE: Yellow Solid on--PoE work normally, Off--PoE doesn’t work, Blink--PoE overload 10/100/1000T RJ45 Interfaces (Port 1 to Port 16): 1000 LNK/ACT (Green), Blink--port connected with data transmission; Solid on--port connected without data transmission  100/1000Mbps SFP Interfaces (Port 17 to Port 20): Green Blink- port connected with data transmission; Solid on- port connected without data transmission EMC Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Dimension 165*145*68mm Weight 1.5kg Working Temperature -40°C to 75°C Storage Temperature -40° to 80°C MTBF 50,000hrs Layer 2 functions Port configuration Auto-negotiation Flow Control Port Mirror: TX/RX/BOTH; Many-to-1 monitor CPU Mirror Traffic statistics Link Aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk) Algorith based on Source/Destination MAC Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address Dynamic MAC address management VLAN 4094 Active VLANs 4094 VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Voice VLAN 802.1ad Q-in-Q tunneling Private VLAN (Protected port) GARP/GVRP ACL 256ACLs L2, L3 e L4 Time-based ACL IP ACL MAC ACL MAC-IP ACL User-Defined ACL ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter Ring Protection <20ms G.8032 ERPS Ring Fast Ring Multicast 256 groups IGMP v1/v2/v3 Snooping, Fast Leave MLD Snooping Multicast VLAN IGMP filter MVR Multicast Routing QOS 8 mapping IDs to 8 level priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port SWRR, DWRR for Scheduling Flow Redirect Precedence TOS Rate Limiting(Ingress/Egress) Stri Priority Security Features Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) ARP Protection AAA DAI DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type; 802.1x Authentication (port-based e MAC-based) TACACS/TACACS+ Authentication RADIUS Authentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port; Port Isolation Loopback detection Management SNMP v1/v2c/v3 with Full Private MIBs RMON 4 groups WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration Backup/Reload Dual Firmware LLDP Configuration Export/Import CDP Aware OAM (IEEE802.3ah) CFM (IEEE802.1ag) sFlow Synchronization, IEEE1588 Support IEEE1588v2 transparent clock Other Features DNS Client DHCP Relay DHCP Client DHCP Snooping DHCP Option 66 DHCP Option 67 DHCP Option 82 NTP/SNTP Client UPNP UDLD PoE management Total PoE power budget control Per port PoE function enable/disable PoE admin-mode control PoE port power feeding priority Per PoE port power limitation PD classification detection PD alive check PoE schedule Soft-reboot PoE Non-stop Maintenance Cable Diagnostics Ping SFP DDM (Digital Diagnostics Monitoring) Thermal protection System log (Local and Remote) Memory and CPU Monitoring Layer 3 functions Static Routing IPv4 Unicast: Static Routing(Software Base) IPv6 Unicast: Static Routing(Software Base) IPV6 IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 Ping6 Telnet(v6) Http/Https Interface IPV6 ACL IPV6

ALLNET Switch industrial full managed Layer2+ 6 Port GbE • PoE Budget 120W • 4x PoE+ • 2x SFP • Fanless • DIN • JSON • ALL-SGI8106PMJ Highlights: 4 Gigabit ports with PoE AF-AT support up to 30 watts per port 2x SFP ports for fibre optic GBIC e.g. ALL4750/4751-INDU etc. PoE ports 1-4 max. PoE IEEE802.3at 30W Layer2+ features such as 802.1Q VLAN, port isolation IGMP, LLDP, PoE+ management, IP source guard, ACLs etc. Supports spanning tree STP (802.1D) and RSTP (802.1W) and MSTP (802.1s) Supports PoE management such as PoE scheduling, PoE PD-alive, port PoE priority, soft reboot PoE non-stop Supports G.8032 quick ring protocol. Self-healing <20ms Max. PoE budget = 120 watts Freeless metal housing with optimised heat dissipation Easy to use as a table-top device, wall-mounted or top-hat rail Extended temperature range from -40°C ~ +75°C NEW: LAN JSON-Java-Script-Notation API for ON/OFF via remote   ALLNET ALL-SGI8106PMJ L2+ managed switch with 4 ports PoE is an industrial switch with 4-port Gigabit 802.3af/at PoE + 2-port Gigabit SFP optical port. It has a robust IP40 housing and a redundant power supply system. The industrial managed switch offers user-friendly but advanced IPv6/IPv4 management interfaces and a soft reboot PoE non-stop function and is the best investment for expanding industrial companies or upgrading their network infrastructure. Intelligent PD alive check for frozen PDs The ALL-SGI8106PMJ industrial PoE switch with 8 ports can be configured to monitor the status of the connected PDs in real time. As soon as the PD stops working and responding, the ALL-SGI8106PMJ restarts the power supply to the PoE port and gets the PD up and running again. In addition, reliability is significantly improved by the fact that the PoE port resets the PD power supply, reducing the administrative burden on the administrator. PoE schedule function for energy saving To protect the environment, the ALL-SGI8106PMJ Ethernet PoE switch can effectively control the power supply in addition to its ability to deliver high wattage. The PoE schedule function helps to enable or disable the PoE power supply for each PoE port during specific time intervals and is a powerful feature that helps SMEs or enterprises to save power and money. Planned PD restart The intelligent PoE switch ALL-SGI8106PMJ allows each of the connected PoE IP cameras or PoE wireless access points to be restarted at a specific time every week. This reduces the risk of the IP camera or AP crashing due to a buffer overflow. Redundant ring with fast recovery for critical network applications The ALL-SGI8106PMJ supports redundant ring technology and has a strong, fast self-recovery capability to prevent interruptions and external intrusions. It integrates advanced ITU-T G.8032 ERPS technology, Spanning Tree Protocol (802.1s MSTP) and a redundant power supply system into the customer's industrial automation network to improve system reliability and uptime in harsh factory environments. In a given simple ring network, the data link recovery time can be as low as 20 ms.   1588 time protocol for industrial computer networks The ALL-SGI8106PMJ is ideal for telecommunications and carrier Ethernet applications and supports MEF service provisioning and timing-over-packet solutions for IEEE 1588 and synchronous Ethernet. Strong Layer 2 functions The ALL-SGI8106PMJ Layer 2 Ethernet switch can be programmed for advanced Layer 2 switch management functions such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. By aggregating the supporting ports, the ALL-SGI8106PMJ enables the operation of a high-speed trunk group that has multiple ports and also supports fail-over. Efficient and versatile management methods For efficient management, the ALL-SGI8106PMJ is equipped with console, web and SNMP management interfaces. With the integrated web-based management interface, it offers a user-friendly, platform-independent management and configuration option. For text-based management, access is possible via Telnet and the console port. For standards-based monitoring and management software, it provides an SNMPv3 connection that encrypts the packet contents for secure remote management during each session. Intelligent PoE switch with SFP DDM function The ALL-SGI8106PMJ supports the SFP DDM (Digital Diagnostic Monitor) function, which allows the network administrator to easily monitor real-time parameters of the SFP transceivers, such as optical output power, optical input power, temperature, laser bias voltage and transceiver supply voltage. The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply unit - please order separately!  JSON-Java Script Object Notation API With the JSON API, the ADMIN can create a special user and grant this user authorisation for JSON. We have focussed on 2 functions that we consider important. PoE ON/OFF & LAN Port Enabled/Disabled (for switches with PoE function) LAN Port Enabled/Disabled (for switches without PoE) Technical details: Model ALL-SGI8106PMJ Copper Ports 4-10/100/1000BASE-T RJ45 auto-sensing ports Fibre ports 2-100/1000BASE-T SFP interfaces, supports 100/1000Mbps dual mode PoE ports 4-802.3af/802.3at PoE injector ports Console ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch architecture Store-and-Forward Switch Fabric 12Gbps/non-blocking Throughput 8.928Mpps @64 bytes Address Table 8K entries Share Data Buffer 4.1 Mb Jumbo Frame 9216 bytes SDRAM 1Gb Flash memory 128Mb Flow Control IEEE 802.3x pause frame for full-duplex ; Back pressure for half-duplex Reset button >2 sec: Factory default and reset Power Supply 48 ~ 57 VDC, 50/60Hz,Dual DC PoE standards IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE PoE Power Supply Type Per port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af) Per port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at) LED indicators Power: Green Solid on–power work normal,off–power disconnected System:Green Blink–work normally, solid on–soft work abnormal, fast blink–soft upgrade PoE: Yellow Solid on–PoE work normally, Off–PoE doesn’t work, Blink–PoE overload 10/100/1000T RJ45 interfaces (Port 1 to Port 4): 1000 LNK/ACT (Green), Blink–port connected with data transmission; Solid on–port connected without data transmission 100/1000Mbps SFP Interfaces (Port 5 to Port 6): Green Blink- port connected with data transmission; Solid on- port connected without data transmission EMC 6KV surge protection (6KV Common Mode, 2KV differential Mode), 6KV contact/8KV air ESD Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Dimension 145x112x47.2mm Weight 0.6kg Working Temperature -40°C to 75°C Storage Temperature -40°C to 80°C Operation Humidity 5% to 95%, non-condensing MTBF 50,000hrs Layer 2 functions Port configuration Auto-negotiation Flow control Port Mirror: TX/RX/BOTH; Many-to-1 monitor CPU Mirror Traffic statistics Link aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk) Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address Dynamic MAC address management VLAN 4094 Active VLANs 4094 VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Voice VLAN 802.1ad Q-in-Q tunnelling Private VLAN (Protected port) GARP/GVRP ACL 256ACLs L2, L3 e L4 Time-based ACL IP ACL MAC ACL MAC-IP ACL User-Defined ACL ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter Ring Protection <20ms G.8032 ERPS Ring Fast Ring ALLNET ring, < 20ms Multicast 256 groups IGMP v1/v2/v3 Snooping, Fast Leave MLD Snooping Multicast VLAN IGMP filter MVR Multicast routing QOS 8 mapping IDs to 8 level priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port SWRR, DWRR for Scheduling Flow Redirect Precedence TOS Rate Limiting(Ingress/Egress) Stri Priority Security Features Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) ARP Protection AAA DAI DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type; 802.1x Authentication (port-based e MAC-based) TACACS/TACACS+ Authentication RADIUS Authentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port; Port Isolation Loopback detection Management SNMP v1/v2c/v3 with Full Private MIBs RMON 4 groups WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration backup/reload Dual firmware LLDP Configuration export/import CDP Aware OAM (IEEE802.3ah) CFM (IEEE802.1ag) sFlow Telnet client Synchronisation, IEEE1588 Support IEEE1588v2 transparent clock Other Features DNS Client DHCP Relay DHCP Client DHCP Snooping DHCP Option 66 DHCP option 67 DHCP option 82 NTP/SNTP client UPNP UDLD PoE management Total PoE power budget control Per port PoE function enable/disable PoE admin-mode control PoE port power feeding priority Per PoE port power limitation PD classification detection PD alive check PoE schedule Soft-reboot PoE non-stop Maintenance Cable Diagnostics Ping SFP DDM (Digital Diagnostics Monitoring) Thermal protection System log (Local and Remote) Memory and CPU Monitoring Tracert/ Tracert 6  Layer 3 functions Static Routing IPv4 Unicast: Static Routing (Software Base) IPv6 Unicast: Static Routing (Software Base) IPV6 IPv6 neighbour discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 Ping6 Telnet(v6) Http/Https Interface IPV6 ACL IPV6

ALLNET Switch industrial full managed Layer2+ 12 Port GbE • PoE Budget 240W • 8x PoE at • 4x SFP • Lüfterless • DIN • JSON API • ALL-SGI8112PMJ-BT-BT Highlights: 8 Gigabit ports with PoE AF-AT support up to 30 watts per port 4x SFP ports for fibre optic gbics e.g. ALL4750-INDU / ALL4751-INDU etc. PoE ports 1-8 max. PoE IEEE802.3at/at/bt max. 90W = total budget 240W Layer2+ features such as 802.1Q VLAN, port isolation IGMP, LLDP, PoE+ management, IP source guard, ACLs etc. Supports spanning tree STP (802.1D) and RSTP (802.1W) and MSTP (802.1s) Supports PoE management such as PoE scheduling, PoE PD-alive, port PoE priority, soft reboot PoE non-stop Supports G.8032 quick ring protocol. Self-healing <20ms Max. PoE budget = 240 watts Freeless metal housing with optimised heat dissipation Easy to use as a table-top unit, wall-mounted or top-hat rail Extended temperature range from -40°C ~ +75°C Hat rail bracket included in the scope of delivery  NEW: PoE & LAN JSON-Java-Script-Notation API for ON/OFF üvia Remote                                                                                                                                                                                                                                                             ALL-SGI8112PMJ-BT Industrial Switch is a managed Layer 2+ Gigabit PoE switch with 8-port Gigabit 802.3af/at PoE and 4-port Gigabit SFP slot port. It is specifically designed to build a full Gigabit backbone to deliver reliable and fast data in demanding industrial environments and to forward data to remote networks over fibre optic cables. It features a robust IP40 enclosure and a redundant power supply system. The industrial managed switch offers user-friendly but advanced IPv6/IPv4 management interfaces and a soft reboot PoE non-stop function. It is the best investment for industrial companies looking to expand or upgrade their network infrastructure. Features: Support of L2+ switching functions including 802.1Q VLAN, mirroring, port isolation, IGMP snooping, DHCP snooping, LLDP, PoE+ management, IP source guard, ARP inspection, ACLs etc. Support for Spanning Tree STP(802.1D) and RSTP(802.1W) and MSTP(802.1s) Support of extended management via WEB, CLI, TELNET, SSH, SNMP. Support for cable diagnostics Two firmware backups Supports PoE management, such as PoE schedule, PoE PD alive, port PoE priority, soft reboot PoE N on-stop Supports G.8032 quick ring protocol. Self-recovery time <20ms Supports IEEE1588 v2, transparent clock (TC) Supports DDM, SFP digital diagnostics & monitoring Supports IPV4 and IPV6 functions for static routing Supports memory and CPU monitoring 6KV &overvoltage protection (6KV common mode, 2KV differential mode), 6KV contact/8KV air ESD protection The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply - please order separately! PoE schedule function for energy saving To protect the environment, the ALL-SGI8112PMJ-BT Ethernet PoE switch can effectively control the power supply in addition to its ability to deliver high wattage. The PoE schedule function helps to enable or disable the PoE power supply for each PoE port during specific time intervals and is a powerful feature that helps SMEs or enterprises to save power and money. Planned PD restart The intelligent PoE switch ALL-SGI8112PMJ-BT allows each of the connected PoE IP cameras or PoE wireless access points to be restarted at a specific time every week. This reduces the risk of the IP camera or AP crashing due to a buffer overflow. Redundant ring with fast recovery for critical network applications The ALL-SGI8112PMJ-BT supports redundant ring technology and has a strong, fast self-recovery capability to prevent interruptions and external intrusions. It integrates advanced ITU-T G.8032 ERPS technology, Spanning Tree Protocol (802.1s MSTP) and a redundant power supply system into the customer's industrial automation network to improve system reliability and uptime in harsh factory environments. In a given simple ring network, the data link recovery time can be as low as 20 ms. 1588 time protocol for industrial computer networks The AALL-SGI8112PMJ-BT is ideal for telecommunications and carrier Ethernet applications and supports MEF service provisioning and timing-over-packet solutions for IEEE 1588 and synchronous Ethernet. Strong Layer 2 functions The ALL-SGI8112PMJ-BT Layer 2 Ethernet switch can be programmed for advanced Layer 2 switch management functions such as dynamic port link aggregation, 802.1Q tagged VLAN, Q-in-Q VLAN, private VLAN, Multiple Spanning Tree Protocol (MSTP), QoS, bandwidth control, IGMP snooping and MLD snooping. By aggregating the supporting ports, the ALL-SGI8112PMJ-BT enables the operation of a high-speed trunk group that has multiple ports and also supports fail-over. Efficient and versatile management methods For efficient management, the ALL-SGI8112PMJ-BT is equipped with console, web and SNMP management interfaces. With the integrated web-based management interface, it offers user-friendly, platform-independent management and configuration options. For text-based management, access is possible via Telnet and the console port. Intelligent PoE switch with SFP DDM function TheALL-SGI8112PMJ-BT supports the SFP DDM (Digital Diagnostic Monitor) function, which enables the network administrator to easily monitor real-time parameters of the SFP transceivers, e.g. optical output power, optical input power, temperature, laser bias voltage and transceiver supply voltage.  The technical features and stable housing make the switch the ideal solution for industrial applications. Supplied without power supply unit - please order separately!  JSON-Java Script Object Notation API With the JSON API, the ADMIN can create a special user and grant this user authorisation for JSON. We have focussed on 2 functions that we consider to be important. PoE ON/OFF & LAN Port Enabled/Disabled (for switches with PoE function) LAN Port Enabled/Disabled (for switches without PoE) Technical details: Model ALL-SGI8112PMJ-BT Copper Ports 8-10/100/1000BASE-T RJ45 auto-sensing ports Fibre ports 4-100/1000BASE-T SFP interfaces, supports 100/1000Mbps dual mode PoE ports 8-802.3af/802.3at PoE Injector Ports Console ports 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1) Switch architecture Store-and-Forward Switch Fabric 24Gbps/non-blocking Throughput 17.856Mpps @64 bytes Address table 8K entries Share Data Buffer 4.1 Mb Jumbo Frame 9216 bytes SDRAM 1Gb Flash memory 128Mb Flow control IEEE 802.3x pause frame for full-duplex ; Back pressure for half-duplex Reset button >2 sec: Factory default and reset Power Supply 48 ~ 57 VDC, 50/60Hz,Dual DC Power consumption without PoE =12W PoE budget max. 240W total PoE standards IEEE 802.3af Power over Ethernet/PSE IEEE 802.3at Power over Ethernet Plus/PSE PoE power supply type Per port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af) Per port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at) LED indicators Power: Green Solid on--power work normal,off--power disconnected System:Green Blink--work normally, solid on--soft work abnormal, fast blink--soft upgrade PoE: Yellow Solid on-PoE work normally, Off--PoE doesn’t work, Blink--PoE overload 10/100/1000T RJ45 interfaces (Port 1 to Port 8): 1000 LNK/ACT (Green), Blink--port connected with data transmission; Solid on--port connected without data transmission 100/1000Mbps SFP Interfaces (Port 9 to Port 12): Green Blink- port connected with data transmission; Solid on- port connected without data transmission EMC 6KV surge protection (6KV common mode, 2KV differential mode), 6KV contact/8KV air ESD Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Dimension 165x123x53.5mm Weight 1.0kg Working temperature -40°C to 75°C Storage Temperature -40°C to +80°C     MTBF 50,000hrs Port configuration Auto-negotiation flow control Port Mirror: TX/RX/BOTH; Many-to-1 monitor CPU Mirror Traffic statistics Link aggregation Static link aggregation LACP(Dynamic Trunk/Static Trunk) Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP MAC Table Aging Time Static MAC address Dynamic MAC address management VLAN 4094 Active VLANs 4094 VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Voice VLAN 802.1ad Q-in-Q tunnelling Private VLAN (Protected port) GARP/GVRP ACL 256ACLs L2, L3 e L4 Time-based ACL IP ACL MAC ACL MAC-IP ACL User-Defined ACL ICMPv6 Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter Ring Protection <20ms G.8032 ERPS Ring Fast Ring Multicast 256 groups IGMP v1/v2/v3 Snooping, Fast Leave MLD Snooping Multicast VLAN IGMP filter MVR Multicast routing QOS 8 mapping IDs to 8 level priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port SWRR, DWRR for Scheduling Flow Redirect Precedence TOS Rate Limiting(Ingress/Egress) Stri Priority Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) ARP Protection AAA DAI DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type; 802.1x Authentication (port-based e MAC-based) TACACS/TACACS+ Authentication RADIUS Authentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port; Port Isolation Loopback detection SNMP v1/v2c with Full Private MIBs RMON 4 groups WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration Backup/Reload Dual firmware LLDP Configuration export/import CDP Aware OAM (IEEE802.3ah) CFM (IEEE802.1ag) sFlow Support IEEE1588v2 transparent clock Other features DNS Client DHCP Relay DHCP Client DHCP Snooping DHCP Option 66 DHCP Option 67 DHCP Option 82 NTP/SNTP Client UPNP UDLD

1x BT 90W PD Input, 2x PoE AT OUT.

1x SFP Input, 1x L/N AC Input mit integriertem Netzteil DC 52VDC/85W Netzteil, 2x BT Output, PoE Budget somit ca. 80W., M25 Connectoren an den Anschlüssen,

Highlights:     With 12*10/100/1000M PoE downlink ports, 4*1000M SFP ports;     Support PoE power each up to 30W;     Support L3 management, such as OSPF, RIP, QoS, VLAN, MSTP, Multi-broadcast, ports management and PoE management;     6KV surge protection, 8KV contact /15KV air ESD protection;     Support working temperature -40°C ~+75°C. ALLNET ALL-SGI8016PM is a professional yet affordable industrial L3 PoE switch with 16 Gigabit ports, supporting up to 12*10/100/1000M PoE downlink ports and 4* 1000M SFP ports. The 12*10/100/1000M ports support PoE+ and comply with IEEE 802.3af/at standard, PoE power per port up to 30W. It supports L3 management such as OSPF, RIP, QoS, VLAN, MSTP, multi-broadcast, port management and PoE management, and supports 6KV surge protection, 8KV contact/15KV air ESD protection. The wall, desktop and din-rail installation is reliable and durable, and can be used in security network video surveillance, network engineering and other occasions. Technical Details: Parameter Specifications Power supply Powered by power adaptor Range of voltage 2*DC 48~57V, redundancy power supply Consumption Self consumption<20W Downlink ports 10/100/1000Base-T 30W PoE RJ45(IEEE 802.3af/at) Uplink ports Ports 13~16 1000M SFP slots Cable and distance Use cat5e/6,100m max Standard IEEE802.3, IEEE802.3u, IEEE802.3z Switch fabric 32Gbps Though put 23.8Mpps Buffer 4M MAC address table 16K Indicator Power: 2 *red ; Uplink 13~16: green LEDs indicate Link/Act Downlink 1~12: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE Protection Surge: 6KV, standard: IEC61000-4-5 ESD: 8KV: contact/15KV: air, standard:IEC61000-4-2 Working temperature -40°C~+75°C Storage temperature -40°C~+85°C Humidity 0~95%(No condensation) Dimension(L×W×H) 165 mm×114 mm×46mm Material Metal Colour Black Net-weight 530g L2 Features Port configuration Auto-negotiation Flow Control Port Mirror L2 Features Link Aggregation Traffic statistics Static link aggregation LACP Algorithm based on Source/Destination MAC Algorithm based on Source/Destination IP 8 groups 8 ports per group L2 Features MAC Table Aging Time Static MAC address Dynamic MAC address management L2 Features VLAN 4K Active VLANs 4K VID 802.1Q Tag VLAN Port VLAN Protocol VLAN MAC VLAN Management VLAN Voice VLAN Q-in-Q Private VLAN GARP/GVRP L2 Features ACL 64 ACLs L2, L3 e L4 Time-based ACL L2 Features Spanning tree 802.1D Spanning Tree Protocol (STP) 802.1w Rapid Spanning Tree Protocol (RSTP) 802.1s Multiple Spanning Tree Protocol (MSTP) Loop Guard Root Guard TC-BPDU Guard BPDU Guard BPDU Filter L2 Features Multicast 256 groups IGMP v1/v2/v3 Fast Leave Multicast VLAN Static Multicast Multicast Filter IGMP Statistics MLD Snooping L2 Features PoE management Support total power consumption control Support single port PoE ON/OFF Support port output priority L2 Features QOS 4 priority queues CoS port-based CoS 802.1p-based CoS DSCP-based Scheduling algorithms SP, WRR, SP+WRR Storm Control (Broadcast, Multicast, Unknown Unicast) Bandwidth control per port Security Features Port Security MAC address filter ARP Association (Manual, ARP scanning, DHCP snooping) up to 200 entries ARP Protection DoS (Denial of Service) Classification of packages based on: End.MAC, IP End, TCP / UDP Ports, Protocol Type 802.1x Autentication (port-based e MAC-based) TACACS/TACACS+ Autentication RADIUS Autentication DHCP Filter Guest VLAN SSLv2/SSLv3/TLSv1 SSHv1/SSHv2 Restriction of WEB access based on: IP Address, And. MAC and Port Port Isolation Local User Name Password Authentication (2 levels) Loopback detection Management SNMP v1/v2c/v3 RMON 4 grupos WEB (HTTP/HTTPS) CLI (Telnet, Console, SSHv1/v2) Firmware upgrade via console/web/TFTP Configuration Backup/Reload All possible configurations in the CLI must exist in the WEB interface LLDP Other Features DHCP Relay DHCP Client DHCP Snooping DHCP Option 82 SNTP Client BOOTP Client Maintenance Ping and Tracert System log (Local and Remote) Memory and CPU Monitoring L3 Features Static Routing OSPFv2 RIPv1/v2 DHCP Server IPV6 IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 Ping6 Tracert6 Telnet(v6) Http/Https IPv6 TFTP Static Routing Interface IPV6

ALLNET Switch unmanaged industrial 3 Port Gigabit 90W / 1x PoE BT 90W / 2x SFP 1G/2,5G / FANLESS / DIN / IP40 / "ALL-SGI8003P-2.5G" Highlights: With 1*10/100/10002.5G Hi-PoE 90W ports and 2*2.5G/1000M SFP ports; Fiber ports provides 2 modes through the dip switch, 2.5GM mode and 1000M mode to adapt to variety needs; Supports relay alarm for power off, network broken and PoE off; Supports PoE Auto-check function, which is specially designed to solve the problems of equipment frozen.It can automatically detect the frozen PD equipment and restart the ports’ output of PSE, and restart the PD device. It greatly reduces the maintenance difficulty of engineering; Supports 6KV surge protection, 6KV contact / 8KV air ESD protection; Supports working temperature -30°C~65°C. The ALLNET ALL-SGI8003P-2.5G represents a state-of-the-art 3-port industrial switch that combines impressive performance with outstanding features. This switch features its 1 *10/100/1000/2.5G high performance copper PoE port that supports PoE end devices with up to 90W. Supported PoE technologies include IEEE802.3af/at as well as IEEE802.3bt with a maximum power of 90W. In addition to this powerful PoE port, the switch provides 2 additional 2.5G/1000M SFP ports for optional SFP modules suitable for both copper and fiber connections (see accessories). A DIP switch makes it easy to switch the SFP slots between 2.5GM mode and 1000M mode. An outstanding feature of the switch is the built-in PoE Auto-Check function, specifically designed to troubleshoot problems with frozen PoE devices. This intelligent feature automatically detects frozen PD devices and resets the output of the PoE copper port to ensure smooth functionality. This significantly reduces maintenance and keeps the technology operating reliably. The switch is DIN-rail compatible and is ideal for applications in security networks, video surveillance systems, networking and AP installations. In environments where high network speeds and significant PoE performance are required, such as WIFI6 infrastructures, the switch proves to be a perfect choice. The scope of delivery includes a manual, a DIN rail clamp and a 5-way Phoenix clamp for power connection. A power supply is not included, but suitable power supplies are available as accessories. With the ALLNET ALL-SGI8003P-2.5G, you are relying on a technologically advanced product that will fit seamlessly into your demanding network requirements. Front-Panel:   Application:   Dimensions: Technical Details: Parameter  Specifications Power supply Powered by power adaptor Range of voltage DC 48~57V Consumption Self consumption<5W Downlink ports Ports 1 10/100/1000/2.5GBase-T 90W PoE RJ45 Uplink ports Ports 2~3 supports 2 modes of 2.5G/1000Base-X PoE Auto-check If detect the frozen PD device, restart it Working mode of fiber ports It can be selected 2.5GM or 1000M work mode by dip switch Relay alarm 1 channel relay alarm output for power off, ports PoE off, ports link down Cable and distance Use cat5e/6,100m max Standard IEEE802.3, IEEE802.3u, IEEE802.3z Switch fabric 15Gbps Though put 11.16Mpps Buffer 1M bits MAC address table 8K Indicator Power: 2 *red ; Uplink2~3: Green LEDs indicate Link/Act Downlink 1: Yellow LED indicate PoE, green LEDs indicate Link/Act Downlink 1: Yellow LED indicate PoE, green LEDs indicate Link/Act Protection Surge: 6KV, standard: IEC61000-4-5 ESD: 6KV: contact / 8KV: air, standard:IEC61000-4-2 Working temperature -30°C~60°C Storage temperature -40°C~85°C Humidity 0~95%(No condensation) Dimension(L×W×H) 101 mm×65 mm×36mm Material Aluminium Colour Black Net-weight 300g Marks CE

ALLNET switch unmanaged industrial 4-port Gigabit 180W / 2x PoE bt / 2x SFP / fanless / DIN / IP40 / "ALL-SGI8004P Highlights: Compact industrial switch with 2x 10/100/1000M PoE copper ports and 2x 1000M SFP ports for GBICS 2x HighPower PoE ports, up to 90 Watt per port; The fiber ports offer 2 modes which can be selected by the dip switch: 100M mode and 1000M mode, to adapt to different requirements; Supports relay alarm for power off, network interruption and PoE off Supports PoE auto check function, which is specially designed to solve the problems of frozen PoE devices. It can automatically detect the frozen PD devices and restart the output of PSE to the ports and reboot the PD device. Support 6KV overvoltage protection, 6KV contact / 8KV air ESD protection. Extended temperature range of -40°~75°. The ALLNET industrial switch ALL-SGI8004P is a very small switch with an extended temperature range of -40°C - +75°C. Due to its small dimensions it is very well suited for switch cabinets and fuse boxes and is also used in industry with strong requirements for dirt and dust protection. Scope of delivery: Manual, top-hat rail clamp, 5-fold Phoenix clamp power connection, switch, no power supply unit included. Technical Details: Parameter Specifications Power supply Powered by power adaptor Range of voltage DC 48~57V "extra power supply needed, see accessories" Consumption Self consumption<5W Downlink ports Ports 1~2 10/100/1000Base-T 90W PoE RJ45 Uplink ports Ports 3~4 supports 2 modes of 100Base-FX and 1000Base-X PoE Auto-check If detect the frozen PD device, restart it Working mode of Fibre Ports It can be selected 100M or 1000M work mode by dip switch Relay alarm 1 channel relay alarm output for power off, ports PoE off, ports link down Cable and distance Use cat5e/6,100m max Standard IEEE802.3, IEEE802.3u, IEEE802.3z Switch fabric 8 Gbps Though put 5.95 Mpps Buffer 1M MAC address table 8K Indicator Power: 2 *red Uplink3~4: Green LEDs indicate Link/Act; Downlink 1~2: Yellow LED indicate PoE, green LEDs indicate Link/Act Protection Surge: 6KV, standard: IEC61000-4-5 ESD: 6KV: contact / 8KV: air, standard:IEC61000-4-2 Working temperature -40°C~75°C Storage temperature -40°C~85°C Humidity 0~95%(Non condensation) Dimension(L×W×H) 101 mm×65 mm×36mm Material Aluminium alloy Colour Black Net-weight 300g Marks CE

Ersatz-DIN-Premium-Halter für ALL-SGI8004P mit Schrauben und Adapterplatte

Highlights: Industrial design, 4x 10/100/1000M Ethernet RJ45 ports with AutoUplink™ and 2 gigabit SFP slots. Supports IEEE802.3x flow control for Full-duplex Mode and back pressure for Half-duplex Mode. RJ-45 port supports Auto MDI/MDI-X. Auto-Negotiation for Full-duplex Mode and Half-duplex Mode. Plug and play, with LED indicators for monitoring power/link/activity, easy to use. Provides DIN35 rail-type installation method. 6KV Surge protection(6KV Common Mode, 2KV differential Mode), 6KV contact/8KV air ESD protection IP40 protection class. Expand DIP function: VLAN: Ports 1-4 can be isolated to each other but can connect to Ports 5 & 6 after open VLAN to stop broadcast Storm to increase forwarding rate of frame. 250m: Transmission extend 250 metres Broadcast Control ALL-SGI8104v3 Industrial Gigabit Ethernet Switch – 6 Ports (4× RJ45 + 2× SFP), DIN-Rail, IP40 The ALL-SGI8104v3 is a high-performance industrial 6-port Gigabit Ethernet switch designed for reliable operation in demanding industrial environments. It features 4 × 10/100/1000M RJ45 Ethernet ports with Auto-Negotiation and 2 × Gigabit SFP slots, enabling flexible network expansion and long-distance fiber connections of up to 120 km. Built with a rugged aluminum extrusion housing, the switch offers excellent resistance to corrosion, electromagnetic interference, vibration, and harsh environmental conditions. Its IP40 protection class and DIN-35 rail mounting make it ideal for industrial automation, control cabinets, transportation systems, and factory networks. The switch supports IEEE 802.3x flow control in full-duplex mode and back-pressure in half-duplex mode, ensuring stable and efficient data transmission. All RJ45 ports support Auto MDI/MDI-X and plug-and-play installation, allowing quick deployment without configuration. Integrated LED indicators provide clear status monitoring for power, link, and network activity. Advanced DIP switch functions allow easy network optimization: VLAN isolation (Ports 1–4 isolated from each other, communication allowed with SFP ports to prevent broadcast storms) Extended transmission mode up to 250 meters Broadcast storm control For maximum network reliability and equipment protection, the ALL-SGI8104v3 is equipped with 6 kV surge protection (6 kV common mode, 2 kV differential mode) and ESD protection (6 kV contact, 8 kV air discharge). With wide industrial power input options and outstanding environmental adaptability, the ALL-SGI8104v3 is an ideal solution for connecting industrial controllers, servers, relays, hubs, terminals, and other network devices in mission-critical applications. Dimension:  Technical Details: Model ALL-SGI8104v3 Interface 4*10/100/1000Base-T RJ45 ports 2*1000Base-X uplink SFP fiber s lot ports Standards Compliance IEEE802.3: CSMA/CD; IEEE802.3i: 10Base-T; IEEE802.3u: 100Base-T; IEEE802.3ab: 1000Base-T; IEEE802.3z: 1000Base-LX SFP Port Characteristic Gigabit SFP fiber interface, default matching optical modules, need to buy separately, (optional order single mode / multi-mode, single fiber / double fiber optical module. Forwarding Mode Store and Forward LED Indicators Power indicator: PWR (green); Network indicator: Link/ACT(green); Power DC 12-57V needs to be bought extra.  Relay Alarm Support Dimension / Weight 145*112.5*45mm/ 0.60kg Operation TEMP / Humidity -40 ~ +75°C;5% ~90% RH Non condensing Storage TEMP / Humidity -40 ~ +85°C;5% ~95% RH Non condensing MTBP 50,000hrs

ALLNET Switch industrial unmanaged Layer2 7 Port GbE • PoE Budget 85W • 4x GbE • 2x SFP • 1x GbE PD • Fanless , IP40 • ALL-SGI807PD Highlights: With 4*10/100/1000M PoE downlink ports,1*10/100/1000M PD ports, and 2*1000M SFP ports, and it supports 4 ports PoE power each up to 30W Provides two modes of Default and VLAN to adapt to various complex environments Supports PoE Auto-check function, which is specially designed to solve the problems of equipment frozen. It can automatically detect the frozen PD equipment and restart the ports’ output of PSE, and restart the PD device.  It greatly reduces the maintenance difficulty of engineering Support 6KV surge protection, 8KV contact/ 15KV air ESD protection Supports relay alarm for power off, network broken, PoE off 2x power supply versions: Version1: PoE IEEE802.3bt with max. 90W then has max. 85W budget. Version2: DC power input 48~57VDC max. PoE budget max. 120W - recommendation: use 240W power supply. (GBICS and switch itself also need power) The ALL-SGI8007PD stands as an industrial PoE switch with 7 ports, offering support for up to 4 *10/100/1000M PoE downlink ports, 1 *10/100/1000M PD port, and 2 *1000M SFP ports. Within the 4 *10/100/1000M ports, PoE+ is facilitated in accordance with IEEE 802.3af/at standards. The ALL-SGI8007PD presents two power supply options: Version 1 employs PoE IEEE802.3bt with a maximum power delivery of 90W and a budget cap of 85W; Version 2 embraces a DC input voltage range of 48~57VDC with a peak PoE budget of 120W - it is advisable to employ a 240W power supply unit (PSU) for optimal performance. (Please note that both GBICs and the switch itself also require a power source.) This switch proffers two distinct modes - Standard and VLAN - meticulously tailored to adeptly adapt within varying complex environments. Furthermore, it integrates the PoE Auto-Check functionality, meticulously devised to counteract challenges arising from device freezing. It effectively identifies frozen PD devices and subsequently triggers a reset of the PSE port outputs, thereby instigating a seamless reboot for the PD device. The outcome culminates in a considerable reduction in maintenance overhead for technicians. Distinguished by virtues of reliability, robustness, durability, and elevated performance, this switch serves as an impeccable solution, finding its niche in security networks, video surveillance systems, network engineering, and a myriad of other domains, rendering it remarkably versatile across diverse scenarios. Example Use cases: Here are some use cases for switches with PoE inputs targeting resellers in the mentioned sectors: Efficient Floor Cabling: In complex networks where workplace switches are powered by a central PoE switch, using PD switches at the workstations reduces the need for individual power supplies and allows time-saving control of ports through the central switch. Security Aspects and Access Control: By being able to turn PoE PD switches on or off on a schedule, the network administrator can regulate power supply to specific devices, thereby controlling access to IP phones, computers, and other devices through network access. Flexible Device Installation: When installing devices like access points or IP cameras in locations without nearby power outlets, PD switches offer an ideal solution. Centralised control facilitates delivering power to remote locations. Large Warehouses and Expansive Sites: In environments like large warehouses or extensive outdoor areas where power supply is a challenge, PD switches combined with PoE repeaters allow reliable power distribution over longer distances. IoT Implementations: When integrating IoT devices in scenarios like smart buildings or industrial environments, PD switches provide the necessary flexibility to operate devices even in hard-to-reach locations. Efficient Smart Home Infrastructure: In smarthome installations, PD switches optimize power distribution and reduce the need for individual power sources for each device. Security Systems and Video Surveillance: In security systems and video surveillance applications, PD switches can ensure power supply for cameras, sensors, and other devices in hard-to-access or strategic areas. Telecommunication Infrastructure: When implementing communication systems in remote locations such as telecommunication masts, PD switches enable reliable communication and power supply. Energy-Efficient Lighting Solutions: In the lighting industry, PD switches can be used to control and power intelligent lighting systems, particularly in places without easily accessible power sources. Cybersecurity and Network Segmentation: PD switches provide the ability to regulate power supply at specific times, enhancing security by restricting network access to certain devices. These diverse use cases illustrate how switches with PoE inputs can provide a flexible and reliable solution to address power supply and networking challenges across various sectors. Technical Details: Parameter Specifications Power supply Powered by power adaptor Range of voltage DC 48~57V Consumption Self consumption<5W Downlink ports Ports 1~4 10/100/1000Base-T 30W PoE RJ45(IEEE802.3af/at) Uplink ports Port 5: 10/100/1000Base-T 90W PoE RJ45; Ports 6~7 1000 SFP slots PoE Auto-check If detect the frozen PD device, restart it Working mode Default mode: normal switch mode. VLAN mode: ports 1~4 are isolated from each other and can only communicate with the uplink port; restrain the network storm; turn off the flow control. Cable and distance Use cat5e/6,100m max Standard IEEE802.3, IEEE802.3u, IEEE802.3z Switch fabric 14Gbps Though put 10.42Mpps Buffer 1M MAC address table 8K Indicator Power: 1 *red ;Uplink5~7: On RJ45 yellow and green LEDs indicate Link/Act Downlink 1~4: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE Protection Surge: 6KV, standard: IEC61000-4-5 ESD: 8KV: contact/ 15KV: air,standard:IEC61000-4-2 Working temperature -40°C ~ 75°C Storage temperature -40°C ~ 85°C Humidity 0~95%(No condensation) Dimension(L×W×H) 165mm×115 mm×50mm Material Aluminum Colour Black Net-weight 500g

Highlights: 10-port 10/100/1000M unmanaged Industrial Ethernet Switch, with 8-port Gigabit RJ45 + 2-port Gigabit SFP optical port. Fanless metal chassis with optimized heat dissipation Easy to use as desktop, wall mount or DIN rail device Extended temperature range of -40° ~ +75° with dialer functions of VLAN, 250m, PD AI IP40 The ALL-SGI8108v2 is an unmanaged 8-port Gigabit industrial switch with 2 Gigabit SFP ports. To ensure a safe and reliable use in industrial environments, the hardware is protected by a rugged metal housing and can be used in the temperature range from -40 to +80 degrees. In terms of mounting, the ALL-SGI8108v2 also offers several options for secure mounting with table, wall or top-hat rail mounting. The delivery is without power supply, please order separately. ALL-SGI8108v2 industrial Ethernet switch has excellent adaptability to industrial environments (including mechanical stability, climate adaptation, electromagnetic environment adaptation, etc.), protection class up to IP40, dual redundant power supply support, low power consumption and fanless cooling technology, MTBF (average trouble-free operation time) up to 5,7 years, plug-and-play, no configuration, easy operation. It is suitable for industrial scenes such as intelligent transportation, rail transportation, electric power, mining, metallurgy and green energy construction, to form a cost-effective and stable communication network. Technical Details: Modell ALL-SGI8108v2 Copper Ports 8-10/100/1000BASE-T RJ45 auto-sensing ports Fiber Ports 2-100/1000BASE-T uplink SFP fiber slot ports Ethernet Port Feature 10/100/1000Base-T automatic detection, full / half duplex MDI/MDI-X adaptive SFP Port Characteristic Gigabit SFP fiber interface, default matching optical modules, need to buy separately, (optional order single mode / multi-mode, single fiber / double fiber optical module. Forwarding Mode Store and Forward(Full Wire Speed) Switch Fabric 20Gbps/non-blocking Troughput 14.88Mpps @64 bytes Share Data Buffer 2 Mb Flash Memory   8Mb Jumbo Frames   9216 Bytes Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP(=100 meter) 10BASE-T: Cat5 UTP (extend PoE 250m DIP-Switch for activate) 100BASE-TX: Cat5 or later UTP(=100 meter) 1000BASE-T: Cat5e or later UTP(=100 meter) Power Supply 12V~57V DC, 50/60Hz,Dual DC Reset Button >2 sec.: Factory default and reset LED Indicators Power: Green Solid on- power work normal, off- power disconnected System: Green Blink-work normally, solid on- soft work abnormal, fast blink- soft upgrade 10/100/1000T RJ45 Interfaces (Port 1 to Port 8): 1000 LNK/ACT (Green), 10/100 LNK/ACT (yellow) Blink- port connected with data transmission; Solid on- port connected without data transmission 100/1000Mbps SFP Interfaces (Port 9 to Port 10): Green Blink- port connected with data transmission; Solid on- port connected without data transmission Power Supply Not included, you can purchase industrial power supply 12VDC - 48VDC, see the accessory information table for purchasing. EMC   Surge Immunity:6KV Per: IEC61000-4-5 ESD Protection: ESD Level 4 Per: IEC61000-4-2;EFT Level 4 Per: IEC61000-4-4 Working Temperature -40 ~ +75°C;5%~90% RH Non condensing Storage Temperature -40 ~ +80°C;5%~95% RH Non condensing Dimensions 165 x 123 x 53.5mm MTBF   50,000hrs   Dimmension:

ALLNET Switch unmanaged 5 Port - 5x GbE - PoE Budget 85W - 4x PoE af/at out 1xPoE bt 90W in - Fanless, DIN, PD-Input - ALL-SG8005PD-BT90 Highlights: Compact switch for DIN rail 5x 10/100/1000M copper ports of which port 2 max. 60W, port 3-5 PoE output ports max. 30W per port, port 1 = PoE PD BT 90W input Compact PoE switch with PD input and PoE outputs for DIN rail  Port 1 PoE output with max. 90W PoE according to IEEE802.3bt - Port 2-5 PoE output with max. 30W according to IEEE802.3af/at - Port 5 PoE PD input Power supply via PoE network, no AC or DC power supply required, supports standard PoE bt, input max 90 W, PoE voltage 44-57 VDC PoE Pin: Input: 1/2 (+), 3/6 (-), 4/5 (+), 7/8(-); Output: 1/2 (+), 3/6 (-) Compact design: L+W+H = 82 x 52 x 23mm Cascading of max. 4 switches possible (no POE left for devices) One Touch VLAN function can be activated via switch. The ALLNET ALL-SG8005PD Gigabit PoE+ Extender/Switch is a compact, high-performance device harnessing the latest network standards to extend your Ethernet signal up to 100 meters per device. With the capability to reach a total range of up to 500 meters, this extender offers flexibility and versatility. Operating via Power over Ethernet (PoE), this amplifier eliminates the need for a separate power supply. This feature allows its deployment in locations without existing power cables or outlets, expanding range or connectivity effortlessly. The 4 PoE ports provide a maximum budget of 85W PoE power. Port 2 delivers up to 60W, while ports 3-5 can supply a maximum of 30W per port. Furthermore, ports 2-5 support both PoE and non-PoE compatible devices, ensuring flexible utilization. This solution is ideal for ensuring a reliable network connection in cabinets or electrical enclosures. The additional ports can accommodate IoT devices or other smart home endpoints, further enhancing the versatility and applications of this extender. The switch offers the option to toggle between two operating modes via a switch: OFF-Normal mode or ON-VLAN & 250M PoE. In VLAN & 250m PoE mode, devices cannot communicate with each other, also known as Port Isolation. Moreover, the network range for 100Mbps devices extends to a maximum of 250m, while Gigabit devices maintain a range of 100m." Technical Details: Technical Details: Modell ALL-SG8005PD-BT90   Product name ALLNET 5 Port PoE Extender Network transmission medium 10Base-T : Cat5e or above UTP(=100m) 100Base-TX : Cat,5e or above UTP(=100m) 1000Base-TX : Cat,5e or above UTP(=100m) Ethernet 4*10/100/1000Mbps PoE Port PoE Output 1*10/100/1000Mbps Ethernet Port Input Transmission distance Bis zu 100m pro Extender Network protocol IEEE802.3 IEEE802.3u IEEE802.3x PoE protocol IEEE802.3bt (90) Input Port 1 IEEE802.3bt (60W Output Port 2 IEEE802.3at (30W) Output Port 3-5 Backplane bandwidth Store and forward MAC address table 1k Switching capacity 10Gbps Forwarding Rate 10BASE-tx: 14880PPS/port 100BASE-tx:148800pps/port 1000BASE-tx:1488000pps/port Port Function Power priority mechanism fast and forward MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode Packet forwarding rate 7.4Mpps PoE inputs 1/2 (+), 3/6 (-), 4/5 (+), 7/8 (-) PoE outputs Ports 1-3 (1/2 +, 3/6-line pair) Port 4 (1/2 +, 3/6-, 4/5 +, 7/8-line pair) Operating temperature -10~55°C Storage temperature -40~85°C Humidity Operating: 10% to 90% relative humidity (non-condensing) Storage: 5% to 95% relative humidity (non-condensing) PoE power Input:DC44-57V 90W Output:DC44-57V 85W PoE voltage 44-57 Vdc Size of the product 82*52*23mm Weight of the product 55g Marks CE

ALLNET Switch unmanaged outdoor 3 Port Gigabit 100W / 3x PoE+ / 1x SFP /  Fanless / IP67 / "ALL-SGO8103P" Highlights: 3-Gigabit ports with PoE AF/AT support up to 30Watt per port, 1x SFP Ports for FO-Gbics e.g. ALL4750-INDU see accessories PoE Ports 1-3 max. PoE IEEE802.3at 30W Max. PoE Budget = 100 Watt Fanless metal housing with optimized heat dissipation Extended temperature range from -40° ~ +75° IP67 Protection class Fanless design The ALL-SGO8103P is a 4-port PoE switch housed within a waterproof IP67 metal casing. This switch offers 3 Gigabit PoE ports compliant with IEEE802.3af/at, delivering a maximum of 30W per port. For the uplink port, the Gigabit SFP slot is recommended, which supports both fiber and copper connections via optional mini-GBICs. It adheres to the IEEE802.3at standard and is additionally compatible with the usage of all IEEE802.3af standard devices, such as wireless APs, network cameras, VoIP phones, base stations, and other high-performance Ethernet terminals. The ALL-SGO8103P is designed for outdoor use. It operates with an input voltage ranging from 100-240Vac and functions efficiently within a temperature range of -40°C to +65°C. This outdoor switch comes equipped with various features including 6kV surge protection and other functionalities to ensure reliable operation in outdoor environments. Optionally, the switch can be easily mounted on a mast using the ALL-SGO83-Pole-Kit. Use Cases: Here are some use cases for the ALL-SGO8103P that cater to our distribution channels selling to resellers in the IT sector, lighting industry, telecommunications sector, electricians, video surveillance sector, security integrators, Industry 4.0 integrators, cybersecurity and IoT professionals, as well as smarthome installers: IT Sector: In IT networks, the ALL-SGO8103P can serve as an outdoor PoE switch to extend networks to remote locations or outdoor areas. For instance, it could be used to power wireless APs in remote areas. Lighting Industry: In outdoor lighting, the switch can be used to control and power PoE-enabled lighting systems, ensuring energy efficiency and flexibility. Telecommunications Sector: For telecommunications, the switch can be used to provide network connectivity to telecommunications masts and equipment outdoors. Electricians: Electricians can utilize the ALL-SGO8103P to install and power PoE-enabled devices such as IP cameras, access control systems, or VoIP phones outdoors. Video Surveillance Sector: In video surveillance, the switch can facilitate the operation and management of PoE-enabled cameras and surveillance devices at strategic outdoor locations. Security Integrators: Security providers can use the switch to install wireless security systems and devices in areas without direct power access. Industry 4.0 Integrators: In Industry 4.0 applications, the switch can aid in connecting and powering networked devices and sensors in outdoor environments. Cybersecurity and IoT: When integrating cybersecurity solutions and IoT devices, the switch can be employed to securely network and power critical devices in outdoor scenarios. Smarthome Installers: Smarthome installers can utilize the switch to operate PoE-enabled devices in the outdoor areas of a residence, such as surveillance cameras or smart lighting systems. These use cases underscore the versatility of the ALL-SGO8103P switch and how it can be deployed across various industries and scenarios to provide robust and reliable outdoor network connections. Technical Drawings: Technical Details: Element Specification Standards IEEE802.3 10Base-T Ethernet IEEE802.3u 100Base-Tx Fast Ethernet IEEE8.2.3ab 1000Base-T Gigabit Ethernet Support PD with IEEE802.3af/IEEE802.3at standard PoE Power Output Mode A = Endspan: 1/2(+), 3/6(–) Auto-detection in accordance with IEEE 802.3at. Mode B = Midspan  4/5(+), 7/8(–) Auto-detection in accordance with IEEE 802.3at. Data rate: 10/100/1000Mbps Output voltage: 55V Output current: 550mA Input AC voltage: 100-240VAC Input AC current: 2A@ 100-240VAC AC Hz: 50-60Hz Grounding information M6 Screw The housing is connected to the PE connection on the power supply. Ideally, the grounding connection on an outdoor housing should have a cross-section of at least 6 mm². Dimensions of the ring cable lug, wire 4.0–6.0 mm², hole 6.5 mm Dimension & Weight Dimension: 176mm X 269mm X 65mm Weight : 1.8kg Environmental & Conditions Operating Temperature: -40°C ~ +65°C Operating Height: -304.8meters to 3048meters Operating Humidiy: Maximum 90%, Non-condensing AC Input Surge Protection 6KV PoE power output surge protection Protected pins: 1, 2, 3, 4, 5, 6, 7, 8 Line - Earth(10/700us): 6KV PoE Surge Protection Protected line: 1,2,3,4,5,6,7,8 Common mode surge protection(10/700us): 6KV Differential mode surge protection (10/700us): 1.5KV EMI FCC CFR47 Part 15, EN55024, EN55032 EMS IEC61000-4-2(ESD) ± 6kV(contact), ±8kV(air) IEC61000-4-3(RS) 10V/m(80MHz~2GHz) IEC61000-4-4(EFT) Power Port: ±2kV; Data Port:±1kV IEC61000-4-5(Surge) Power Port:±1kV/DM, ±2kV/CM IEC61000-4-6(CS) 10V(150kHz~80MHz) Immunity IEC60068-2-6(Vibration) IEC60068-2-27(Impact) IEC60068-2-32(Free Fall) Marks CE IP67 WEEE Compliance Protection Level: IP67 IEC60529, NEMA 250

2er Set Blindstopfen M22 mit O-Ring

Outdoor installation Kit(Pole mounting) Mini Pole diameter:25mm(1 inch) Max Pole diameter:101.6mm(4 inch)

5-Port Aluminum Industrial Light Managed Switch, 5 10/100/1000Mbps Ports, 4 PSE Ports, 802.3at/af, 1 1000Mbps SFP Port, IP40, work temperature:-40°C~85°C, Din-Rail & Wall mounts installation, Dual-Power Redundancy, wide voltage range DC 9.6~60V, Polarity Reverse Protection, Short Circuit Protection, Local Management via Web GUI, Support Port Management/VLAN/Loop Detection/BSP, Power Adapter Not Included

5-Port Aluminum Industrial Light Managed Switch, IP40, work temperature:-40°C~85°C, 1000Mbps 5-Port RJ45, 1000Mbps 1-Port SFP, Din-Rail & Wall mounts installation, Dual-Power Redundancy, wide voltage range DC 9.6~60V, Polarity Reverse Protection, Short Circuit Protection, Local Management via Web GUI, Support Port Management/VLAN/Loop Detection/BSP, Power Adapter Not Included

8-Port Aluminum Industrial Light Managed Switch, 8 10/100/1000Mbps Ports, 8 PSE Ports, 802.3at/af, 2 1000Mbps SFP Port, IP40, work temperature:-40°C~85°C, Din-Rail & Wall mounts installation, Dual-Power Redundancy, wide voltage range DC 9.6~60V, Polarity Reverse Protection, Short Circuit Protection, Local Management via Web GUI, Support Port Management/VLAN/Loop Detection/BSP, Power Adapter Not Included

8-Port Aluminum Industrial Light Managed Switch, IP40, work temperature:-40°C~85°C, 1000Mbps 8-Port RJ45, 1000Mbps 2-Port SFP, Din-Rail & Wall mounts installation, Dual-Power Redundancy, wide voltage range DC 9.6~60V, Polarity Reverse Protection, Short Circuit Protection, Local Management via Web GUI, Support Port Management/VLAN/Loop Detection/BSP, Power Adapter Not Included

8 10/100/1000 BASE-T PoE+ Ports , plus 4 100/1000BASE-X SFP Industrial Gigabit Ethernet Switch
